BASIC OPERATIONS
77144 Issue 8 August 2009 35
HEAD MOUNTED BOX GUIDE
Some conveyors require extra guidance rails for the
boxes to travel on the conveyor without twisting or
hitting the control unit. The head mounted box
guide rail controls the distance between box and
print head and also corrects the misalignment of
boxes that have moved out of the correct printing
path. The box guide should only be used in
conjunction with conveyor guide rails. For
installation instructions on this box guide refer to
your local Domino office. Instructions for changing
the ink collection sponge are on page 131.
Box
guide
rail
Buffer plateBox Guide
Ink drip tray
and ink
collection
sponge
To Next Page
