Domino C6000 plus User Manual

PROGRAMMING THE PRINTER
78 77144 Issue 8 August 2009
CHECKING CURRENT BOX COUNT
The printer is capable of counting the number of boxes that have passed the sensor.
The box count function can be zeroed at any point and will count in single
increments from zero. Check the box count as follows:
(1) Scroll through the main menu bar on the LCD with the directional arrow
keys and select the current box count icon.
(2) The current box count figure will be
displayed, in this example 99. Below the box
count number is “Do you wish to zero this
value?” If the value needs to be reset back to
zero, press the enter key. If the current
value is still required, press escape to return to the main menu.
Note: It is possible to print box counts and pallet counts. These functions are set up
under the
counting icon which is located under the edit which message?
menu.
(3) On pressing enter, the following screen is
displayed, press enter to zero the box count
or press Esc to resume the count.
123
Press right
hand
directional key
until the menu
bar starts to
scroll
Press the
corresponding
key to select
the function
PRINTING MESSAGE1
NORMAL PRINT
INK STATUS OK
123
CURRENT BOX COUNT IS
99
DO YOU WISH TO
ZERO THIS VALUE
E
SC
123
CURRENT BOX COUNT IS
99
DO YOU WISH TO
ZERO THIS VALUE
PRESS TO CONFIRM
OR ESC TO RESUME
