BASIC OPERATIONS
60 77144 Issue 8 August 2009
LCD Screen Icons
ROOT LEVEL, MENU
BAR ICONS
NAME & DESCRIPTION
Print which message?, select a saved message to
be printed from the control unit’s memory.
Edit or create a message?, to format a new
message, update or edit an old message.
Parameters of the message can be altered, e.g.
print speed, DPI, delay, adjusting the bar codes or
copying current message parameters as the default
settings.
Prime print head, it is recommended the prime
function is performed every time the printer is
started or any time the nozzle plate requires
cleaning.
Product direction, depending on which side of
the conveyor the printer is mounted, will
determine whether the message is printed from left
to right or right to left.
Enter new time, can be adjusted at any point.
Details of time, date, month and day can be
entered for printing.
Rollover time, the default rollover time is set to
midnight. This is when the system clock will
rollover on to a new day. The rollover function can
be changed to suit.
Enter number of shifts, the printer can keep a
track of the shifts during the running time of the
production line, this icon allows the selection of
between 1-4 different shifts.
To Next Page
