DV11
Operation and Maintenance
26
Technical Information
Printed in Mar. 2005 PS-MMA0608-E1A
- Adjust the tension of poly belt
when pressed down with
specified force (F kg):
T = 0.015 x S
(Deflection : 1.5 mm per 100 mm)
2.3.11. Air cleaner
z In case that elements are
deformed, damaged or if the air
cleaner has a crack, replace it.
(genuine parts use)
z By the definite interval, the
elements must be cleaned and
replaced.
2.3.12. Pre fuel filter
z Drain water in cartridge with
loosening the drain plug under
cartridge manually from time to
time.
z The filter cartridge should be
replaced at every 40,000 km.
2.3.13. Fuel filter
z The filter cartridge should be
replaced at every 40,000 km.
Priming pump
Pre fuel filter &
cartridge
Drain plug
Fuel filter &
cartridge
To Next Page
