DV11
Operation and Maintenance
57
Engine Disassembly
Printed in Mar. 2005 PS-MMA0608-E1A
3.1.9. Oil filter
z Loosen the filter housing fixing
bolts then the spring will force the
filter housing to move upward a
little.
z Do not use again the cartridge
removed after use.
z Unscrew the oil filter head fixing
bolts and take off the oil filter head.
3.1.10. Alternator
z Remove the supporting guide piece
for installing the alternator and the
bracket bolts.
z Disassemble the alternator.
3.1.11. Turbocharger
z Loosen the hose clamp for
connecting the intake stake and
tear down the air pipe.
z Unscrew the turbo charger
lubrication supplying bolt and tear
down oil pipe
z Unscrew the turbo charger fixing
nuts and take off the turbo charger
from the exhaust manifold.
