DV11
Operation and Maintenance
32
Technical Information
Printed in Mar. 2005 PS-MMA0608-E1A
2.3.21. Cooling system
The engine has a liquid-cooling system. The fresh water pump is a maintenance-free
by belt from the crankshaft pulley.
z Check the coolant level of the expansion tank by removing the expansion tank
filler cap, and add coolant if necessary
z When injecting antifreeze solution, first drain out the old coolant from the cylinder
block and radiator, and then clean them with cleaning solution.
z Be sure to mix soft water with antifreeze solution.
Radiator
Cylinder block
Water pump
Thermostat
Oil cooler
Cylinder head
Cylinder head
Cylinder No
