Doosan DV11 - Cylinder Head; Oil Pan; Oil Pump

DV11
Operation and Maintenance
65
Engine Disassembly
Printed in Mar. 2005 PS-MMA0608-E1A
3.1.30. Cylinder head
z Loosen the cylinder head fixing
bolts in the reverse order of
assembling, and remove them all
and then take the cylinder head out.
z Remove the cylinder head gasket
and scrap it.
z Eliminate the residue from the
cylinder head face and cylinder
block face.
CAUTION:
Be careful not to damage the
cylinder head face where its
gasket contacts.
3.1.31. Oil pan
z Remove the oil pan fixing bolts and
separate the oil pan.
z Remove the oil pan gasket and
scrap it.
3.1.32. Oil pump
z Remove the oil suction pipe fixing
bolts and tear them down.
z Remove the oil pump fixing bolts
and separate it.
Cylinder head bolt
Disassembly order no.
