Technical Information
- 23 -
z
The injection pump and the turbocharger are also connected to the engine lubricating system. The
cylinder walls and timing gears are splash-lubricated.
Each cylinder has an oil jet provided for cooling the underside of the pistons.
The lube oil is cleaned in a full-flow oil filter. Depending on the agreed extent of delivery and the
design of the engine, the lube oil circuit can be equipped with oil pressure monitors (advance
warning and cut-off function) which shut the engine down in the event of a sudden loss of pressure.
(1) Oil cooler
An oil cooler is provided between the oil filter and the crankcase. This cooler is of the flat tube
type with turbulence inserts and operated by the coolant.
2.2.7. Engine cooling system
EA6M1001
Coolant pipe
Coolant pipe
Thermostat
Water pump
Cylinder head
Oil cooler
Radiator
