Engine Disassembly
- 61 -
3.1.31. Camshaft and tappet
z
Pull out the tappets from the cylinder
block.
z
Remove the camshaft being careful not
to damage the camshaft and its
bearings.
3.1.32. Oil spray nozzle
z
Remove the oil injection nozzle fixing
bolts and tear down the oil injection
nozzles.
3.1.33. Cylinder liner
z
By means of a special tool (Extractor),
pull out the liner from the cylinder block.
EFM2059I
EFM2030I
