Technical Information
- 36 -
z
Adjusting Sequence of Valve Clearance
This is a precision method, but it takes more time.
* 8 Cylinder Engine (P158LE/PU158TI)
* 10 Cylinder Engine (P180LE/PU180TI)
* 12 Cylinder Engine (P222LE/PU222TI)
–
No. 1 Cylinder is located at the side where cooling water pump was installed.
Valve overlapping on cylinder
(Intake & Exhaust valve)
15726348
Adjusting valves on cylinder
(Intake & Exhaust valve)
63481572
Valve overlapping on cylinder
(Intake & Exhaust valve)
16510273849
Adjusting valves on cylinder
(Intake & Exhaust valve)
73849165102
Valve overlapping on cylinder
(Intake & Exhaust valve)
112583106721149
Adjusting valves on cylinder
(Intake & Exhaust valve)
672114911258310
7
8
9
10
11
12
1
2
3
4
5
6
12
11
10
9
8
7
6
5
4
3
2
1
6
7
8
9
10
1
2
3
4
5
10
9
8
7
6
5
4
3
2
1
5
6
7
8
1
2
3
4
8
7
6
5
4
3
2
1
EA6O6008
8 Cylinder engine 10 Cylinder engine 12 Cylinder engine
Flywheel
Cooling fan
