192 Instructions for use | Atlan A100 (XL), A300 (XL), A350 (XL) SW 2.1n
Alarms
10.2.3 Overview of alarm priorities
Every alarm is assigned a certain priority that reflects its urgency.
10.3 Response to alarms
10.3.1 Displaying information on alarms
1. Information on the alarms can optionally be displayed as follows:
– Touch the alarm in the header bar.
– Open the Alarms dialog and touch the Current alarms tab (1).
2. In the list (2), touch the corresponding alarm or select it with the rotary knob.
3. Refer to the information under Cause (4) and Remedy (3) to remedy the error.
A list of all possible alarms can be found in chapter "Alarm – Cause – Remedy",
see page 245.
Priority Back-
ground
color
Marking in the
logbook and in
the chapter enti-
tled "Alarm –
Cause – Remedy"
Need for action
High Red !!! Immediate action required to avert
an acute hazard
Medium Yellow !! Immediate action required to avert a
hazard
Low Cyan ! Take note or action required
36003
1
2
3
4
