Instructions for use | Atlan A100 (XL), A300 (XL), A350 (XL) SW 2.1n 245
Troubleshooting
12.13 Support request
If the device is configured for remote maintenance, device information can be sent
to Dräger in the event of a problem. Proceed as follows to send a support request to
Dräger:
1. In the Standby mode, touch the Tests... button.
2. Touch the Request support button.
12.14 Alarm – Cause – Remedy
Alarm messages are displayed in hierarchal order in the alarm message field of the
header bar, see page 192.
Different background colors indicate the priority levels of the alarms.
In the Current alarms and Logbook tables, the priority of the alarm messages is also
indicated by exclamation marks.
Every alarm priority (high, medium, low) shown on screen is subdivided into further
classifications by an internal priority number between 0 and 255. If several alarm
messages of the same alarm priority are active at the same time, the internal
priority number defines the order of the displayed alarm messages within the same
alarm priority. A more critical alarm message of one alarm priority has a higher
priority number than a less critical alarm message of the same alarm priority.
In the following example with three active alarm messages, the etCO
2 low and
Minute volume low alarm messages have a medium alarm priority (!!) and are
displayed above the O
2 cylinder almost empty alarm message, which has a low
alarm priority (!). The display order of the two alarm messages with medium priority
(!!) is defined by the internal priority number. Due to its higher priority number 135,
the etCO
2 low alarm message is displayed above the Minute volume low alarm
message with priority number 80.
If the alarm priority and internal priority number of several alarm messages are the
same, the newer alarm message will be displayed above the older alarm message.
In the following table, the alarm messages are listed in alphabetical order. If an
alarm occurs, the table helps to identify causes and remedies. The different causes
and remedies should be worked through in the order listed until the alarm has been
resolved.
Some alarms are listed several times because their priority may change under
certain conditions, see page 198.
Alarm priority Indicator Priority number Background color
High !!! 0 - 255 Red
Medium !! 0 - 255 Yellow
Low ! 0 - 255 Cyan
Alarm Priority Display order on screen
etCO
2 low !! 135 1.
Minute volume low !! 80 2.
O
2 cylinder almost empty ! 220 3.
