200 Instructions for use | Atlan A100 (XL), A300 (XL), A350 (XL) SW 2.1n
Alarms
10.6 Activation of alarms after breath detection
Devices equipped with inspiratory O2 measurement and integrated patient-
gas measurement module
In the Man/Spon mode, the alarms for Minute volume low and Apnea (no flow) are
only activated after spontaneous breaths have been detected.
Devices equipped with integrated patient-gas measurement module
If still no breaths have been detected after leaving the Standby, Pause, or
Monitoring modes, the breathing gas is monitored with regard to an O
2
concentration that is too low or an anesthetic gas concentration that is too high. At
the same time, the message Waiting for respiratory phases is displayed in the
CO
2 waveform.
Once 2 breaths have been detected, the message disappears and only then are the
O
2, CO2, N2O, and anesthetic gas alarms active.
Tidal volume not
achieved
--- After 3 consecutive
breaths
---
Airway press. continu-
ously high
--- --- >15 s above the auto-
matically set limit
Inspiratory pressure
not achieved
--- After 3 consecutive
breaths
---
Cardiac bypass mode
still active?
--- If a minute volume of
>50 % of the suggested
value is measured after
CBM mode has been
activated for >60 s
---
Fresh gas low or leak-
age
--- Breathing bag empty In the event of an addi-
tional "Apnea (no flow)",
"Apnea (no pressure)",
or "Inspiratory pressure
not achieved" alarm
Backup manual mode
activated
>20 s --- 0 to 20 s
Alarm Priority Priority Priority
Low Medium High
