17.4 Overview of the menu structure
The following tables list the buttons of the main menu bar with the resulting dialogs
of the same name and the tabs. For further information see: "Operating concept",
page 97. The structure of the main screen and the dialogs is illustrated on pages 97
and 98.
Group
Button in main menu
bar
Horizontal tab Vertical tab Description
Alarms... Limits Display or change alarm limits.
Current alarms Display information on active alarms.
Logbook View alarm logbook.
Settings Set the alarm volume.
Activating or deactivating CO
2 alarms
1),2)
.
Switch CBM mode on or off
1)
.
1) Only during operation, not in Standby mode
2) Only available for the device equipped with integrated patient-gas measurement module
CO2 alarms off
1),2),3)
3) Only in the modes: Manual / Spontaneous, Ext. FGO, Pause, Monitoring
Deactivate CO2 alarms.
Autoset limits
1),4)
4) Only in the modes: PSV, PC, VC - CMV / AutoFlow, VC - CMV
Automatically adapt alarm limits to current
measured or set values.
Exit CBM
1),5)
5) Only in CBM mode
Exit CBM mode.
Group
Button in main menu
bar
Horizontal tab Vertical tab Description
Views...
1)
1) Only during operation, not in Standby mode
Switch to other configured views.
Reset current view to start setting.
Display alarm limits, units, mini-trends,
and loops.
View
1)
View
1)
View
1)
Switching between the 3 configured
views.
Export screenshot Export screenshot to a USB mass storage
device.
123
123
123
