7.9.8.2 Acknowledge manually:
The pump switches to Pause on empty signal and the empty signal symbol is displayed in
red . After pressing the red empty signal symbol, the container change must first be
approved on the screen and the suction pipe can then be moved to a new container
.
Fig. 55: Select Acknowledge manually
[Acknowledge automatically] - setting:
1.
[Main menu] :
Ä
Chapter 7.6 ‘Main menu’ on page 66
2.
[Configuration menu] :
Ä
Chapter 7.9 ‘Overview - Configuration’ on page 83
3. Use the scrollbar to scroll to the [Select empty signal]
menu option.
4. [Select empty signal] - select.
5. If required, ‘empty message contact’: ‘closed contact = select empty signal’
ð
After selecting this, a check mark is set in the selection field.
6.
[ Press the Next button] .
ð
Screen changes to the acknowledgement query of the ‘empty signal’.
7. [Select Acknowledge manually] - select.
8.
Pressing the button saves the setting.
ð
The screen switches to the overview: [Configuration menu].
9.
Pressing the button returns to the [Main menu].
10.
Pressing the button returns to the [Operating display].
Control / software
96Rev. 2-05.2018
