Fuji Xerox ApeosPort Print C5570 User Manual

237
10.3 Installing the Envelope Tray
10.3 Installing the Envelope Tray
Installing the envelope tray
Remove Tray 1 installed as standard from the machine, and then install the optional Envelope Tray on the machine.
Important

Install the envelope tray in the location of Tray 1. It cannot be installed at any other tray location.
1. Pull out the Tray 1 until it stops.
2. Lift the front of Tray 1 slightly and remove Tray 1 from the machine.
Note

When removing the tray, lift up the back side high, while lifting the front side slightly.
3. Move the materials stored within the cover on the front right of the tray from Tray 1 to the Envelope Tray.
