CHAPTER 3: ETHERNET INTERFACE DNP ETHERNET PROTOCOL SETTINGS
SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 3-13
DNP port allocation
The DNP Eth Channel 1 Port and DNP Eth Channel 2 Port settings select the
communications port assigned to the DNP protocol for each Ethernet channel. When this
setting is set to "Network-TCP" the DNP protocol can be used over TCP/IP channels 1 or 2.
When this value is set to "Network-UDP" the DNP protocol can be used over UDP/IP on one
channel only.
□ Configurable □ When Device Restarts
□ Only certain objects □ When Status Flags Change
⊠ Sometimes No other options are permitted.
⊠ ENABLE/DISABLE unsolicited Function codes
supported
Explanation of ‘Sometimes’: It will be disabled for
RS-485 applications, since there is no collision
avoidance mechanism. For Ethernet communication
it will be available and it can be disabled or enabled
with the proper function code.
Default Counter Object/Variation: Counters Roll Over at:
□ No Counters Reported □ No Counters Reported
□ Configurable (attach explanation) □ Configurable (attach explanation)
⊠ Default Object: 20 ⊠ 16 Bits
Default Variation: 1
⊠ Point-by-point list attached □ Other Value: _____
⊠ Point-by-point list attached
Sends Multi-Fragment Responses:
⊠ Yes
□ No
DNP 3.0 Device Profile
Channel 1 Port Channel 2 Port DNP Availability
None None DNP not available over Ethernet port
None NETWORK-TCP One Master over TCP
None NETWORK-UDP "Various" Masters over UDP
NETWORK-TCP None One Master over TCP
NETWORK-TCP NETWORK-TCP Two Masters over TCP
NETWORK-TCP NETWORK-UDP One Master over TCP and "various" Masters over UDP
NETWORK-UDP None "Various" Masters over UDP
NETWORK-UDP NETWORK-TCP "Various" Masters over UDP and one Master over TCP
NETWORK-UDP NETWORK-UDP "Various" Masters over UDP
