3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE A–45
3.3 Common data class specifications for controllable status information
3.3.1 Controllable single point (SPC)
SPC_0
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C/E
DataAttribute
control and status
Oper ctlVal Boolean CO AC_CO_M
origin Originator CO AC_CO_M
orCat ENUMERATED M
orIdent OCTECT64 M
ctlNum INT8U CO M
T Btime6 CO M
Test Boolean CO M
Check ENUMERATED CO M
stVal Boolean ST FALSE | TRUE AC_ST
q Quality ST AC_ST
t TimeStamp ST AC_ST
configuration, description and extension
ctlModel ENUMERATED CF ctlModel_1 M
operTimeout INT32U CF AC_CO_O
cdcNs Vstring255 EX GE Multilin SR3
Namespace:2003
AC_DLNDA
_M
cdcName Vstring255 EX SPC AC_DLNDA
_M
SPC_1
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C/E
DataAttribute
control and status
stVal Boolean ST FALSE | TRUE AC_ST
q Quality ST AC_ST
t TimeStamp ST AC_ST
configuration, description and extension
ctlModel ENUMERATED CF ctlModel M
