3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE A–1
3 Series Protective Relay Platform
Appendix A: IEC 61850
Implementation Details
GE
Grid Solutions
IEC 61850 Implementation Details
MICS
This sections contains the Model Implementation Conformance Statement (MICS) for the
IEC 61850 interface in 3 Series Family of protective relays.
Date: January 31, 2017
Version: 1.13
1 INTRODUCTION
This model implementation conformance statement is applicable for 3 Series Family, with
firmware 2.30:
This MICS document specifies the modelling extensions compared to IEC 61850 edition 1.
For the exact details on the standardized model please compare the ICD substation
configuration file: SR350.icd, SR339.icd, SR345.icd, version 2.30.
• Clause 2 contains the list of implemented logical nodes.
• Clause 3 describes the new and extended logical nodes.
• Clause 4 describes the new and extended common data classes.
1.1 Logical Nodes List
The following is a list of logical nodes and number of instances that will be supported*
within the 3 Series relays:
*Note: Depending on the relay order code, the number of LN may changer.
