3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE A–61
PIXIT for Reporting model
PIXIT for Logging model
ID Ed Description Value / Clarification
Rp1 1 The supported trigger conditions are
(compare PICS)
integrity
data change
quality change
data update
general interrogation
Y
Y
Y
N
N
Y
Rp2 1 The supported optional fields are sequence-number
report-time-stamp
reason-for-inclusion
data-set-name
data-reference
buffer-overflow
entryID
conf-rev
segmentation
Y
Y
Y
Y
Y
Y
Y
Y
Y
Rp3 1,2 Can the server send segmented reports Y
Rp4 1,2 Mechanism on second internal data change
notification of the same analogue data value within
buffer period (Compare IEC 61850-7-2 $14.2.2.9)
Send report immediately
Rp5 1 Multi client URCB approach
(compare IEC 61850-7-2:2003 $14.2.1)
Each URCB is visible to all
clients
Rp6 - What is the format of EntryID Deprecated
Rp7 1,2 What is the buffer size for each BRCB or how many
reports can be buffered
Buffer size = 50000 Bytes
Rp8 - Pre-configured RCB attributes that are dynamic,
compare SCL report settings
Deprecated
Rp9 1 May the reported data set contain:
- structured data objects
- data attributes
Y
Y
Rp10 1,2 What is the scan cycle for binary events
Is this fixed, configurable
Event Driven
Fixed
Rp11 1 Does the device support to pre-assign a RCB to a
specific client in the SCL
N
Rp12 2 After restart of the server is the value of ConfRev
restored from the original configuration or retained
prior to restart
Restored from original
configuration
ID Ed Description Value / Clarification
Lg1 1,2 What is the default value of LogEna
(Compare IEC 61850-8-1 $17.3.3.2.1, the default value
should be FALSE)
NOT SUPPORTED
Lg2 - What is the format of EntryID Deprecated
Lg3 1,2 Are there are multiple Log Control Blocks that specify the
Journaling of the same MMS NamedVariable and TrgOps
and the Event Condition
(Compare IEC 61850-8-1 $17.3.3.3.2)
NOT SUPPORTED
Lg4 1 Pre-configured LCB attributes that cannot be changed
online
NOT SUPPORTED
