A–64 3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
PIXIT
PIXIT for Control model
ID Ed Description Value / Clarification
Ct1 - What control models are supported
(compare PICS)
Deprecated
Ct2 1,2 Is the control model fixed, configurable and/or dynamic Configurable & Dynamic
Ct3 - Is TimeActivatedOperate supported (compare PICS or SCL) Deprecated
Ct4 1,2 Is "operate-many" supported (compare sboClass) Deprecated
Ct5 1 Will the DUT activate the control output when the test attribute is set in
the SelectWithValue and/or Operate request (when N test procedure Ctl2
is applicable)
N
Ct6 - What are the conditions for the time (T) attribute in the SelectWithValue
and/or Operate request
Deprecated
Ct7 - Is pulse configuration supported (compare pulseConfig) Deprecated
Ct8 1 What is the behaviour of the DUT when the check conditions are set
Is this behaviour fixed, configurable, online changeable
N synchrocheck
N interlock-check
DUT ignores the check value and always
perform the check
Ct9 1,2 Which additional cause diagnosis are supported Y Unknown
Y Not-supported
Y Blocked-by-switching-hierarchy
Y Select-failed
Y Invalid-position
Y Position-reached
N Step-limit
N Blocked-by-Mode
N Blocked-by-process
N Blocked-by-interlocking
N Blocked-by-synchrocheck
Y Command-already-in-execution
N Blocked-by-health
N 1-of-n-control
N Abortion-by-cancel
Y Time-limit-over
N Abortion-by-trip
Y Object-not-selected
Edition 1 specific values:
N Parameter-change-in-execution
Edition 2 specific values:
N Object-already-selected
N No-access-authority
N Ended-with-overshoot
N Abortion-due-to-deviation
N Abortion-by-communication-loss
N Blocked-by-command
N None
N Inconsistent-parameters
N Locked-by-other-client
N Parameter-change-in-
execution
Ct10 1,2 How to force a "test-not-ok" respond with SelectWithValue request Device in local mode
Ct11 1,2 How to force a "test-not-ok" respond with Select request Device in local mode
Ct12 1,2 How to force a "test-not-ok" respond with Operate request DOns: Sending T=1
SBOns: Sending T=1
DOes: Sending T=1
SBOes: Sending T=1
Ct13 1,2 Which origin categories are supported / accepted N bay-control
Y station-control
Y remote-control
N automatic-bay
Y automatic-station
Y automatic-remote
N maintenance
N process
