3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE A–19
2.2.13 PVPH (Volts per Hz)
PVPH: Volts per Hz
2.3 Logical Nodes for protection related functions. LN Group: R
2.3.1 RDIR (Directional element)
phsRDIR: phase directional overcurrent
PVPH class
Attribute Name Attr. Type Explanation M/O/C/E Notes
PVPH Volts per Hz
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Start M Volts Hz PKP
Op ACT_2 Operate M Volts Hz OP
Blk ACT_3 Block E Volts Hz BLK
RDIR class
Attribute Name Attr. Type Explanation M/O/C/E Notes
PhsRDIR Directional Element
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Dir ACD_0 Directions M
Op ACT_5 Operate E
Blk ACT_3 Block E
