A–32 3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS
3 COMMON DATA CLASS
3.1 Common data class specifications for status information
3.1.1 Single Point Status (SPS)
3.1.2 Integer Status (INS)
SPS_0
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C/E
DataAttribute
status
stVal Boolean ST dchg M
q BVstring13 ST qchg M
t Utctime ST M
configuration, description and extension
d Vstring255 DC O
SPS_1
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C/E
DataAttribute
status
stVal Boolean ST dchg M
q BVstring13 ST qchg M
t Utctime ST M
INS_0
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C/E
DataAttribute
status
stVal Enum ST dchg Beh M
q BVstring13 ST qchg M
t Utctime ST M
INS_1
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C/E
DataAttribute
status
stVal Enum ST dchg Health
1: when normal. (No errors)
2: when minor error is
present (e.g. "High ENET
Traffic" alarm)
3: when major error is
present. (e.g. "Error Code 1"
or "RELAY NOT READY")
M
q BVstring13 ST qchg M
t Utctime ST M
