GE 350 User Manual

CHAPTER 3: ETHERNET INTERFACE DNP ETHERNET PROTOCOL SETTINGS
SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 3-17
NOTE
NOTE:
1. A default variation refers to the variation response when variation 0 is requested and/
or in class 0, 1, 2, or 3 scans. The default variations for object types 1, 2, 20, 21, 22, 23,
30, and 32 are selected via relay settings. This optimizes the class 0 poll data size.
2. For static (non-change-event) objects, qualifiers 17 or 28 are only responded when a
request is sent with qualifiers 17 or 28, respectively. Otherwise, static object requests
sent with qualifiers 00, 01, 06, 07, or 08, will be responded with qualifiers 00 or 01 (for
change event objects, qualifiers 17 or 28 are always responded.)
Cold restarts are implemented the same as warm restarts – the 3 Series relay is not
restarted, but the DNP process is restarted.
DNP Ethernet EnerVista Setup
Table 3-1: DNP protocol
2 Class 1 Data 1 (read) 20
(enable unsol)
06 (no range, or all)
07, 08 (limited
quantity)
--- ---
3 Class 2 Data 21 (disable unsol) --- ---
4 Class 3 Data 22 (assign class) --- ---
80 1 Internal Indications 1 (read) 00, 01 (start-stop)
(index =7)
129 (response) 00, 01 (start-stop)
2 (write) (see
Note 3)
00 (start-stop) (index
=7)
--- ---
No Object (function code
only) see Note 3
13 (cold restart) --- --- ---
No Object (function code
only)
14 (warm restart) --- --- ---
No Object (function code
only)
23 (delay meas.) --- --- ---
OBJECT REQUEST RESPONSE
OBJECT
NO.
VARIATION
NO.
DESCRIPTION FUNCTION
CODES (DEC)
QUALIFIER CODES
(HEX)
FUNCTION
CODES (DEC)
QUALIFIER CODES
(HEX)
SETTINGS PARAMETER RANGE FORMAT
DNP Channel 1 Port NONE NONE ; NETWORK-TCP ;
NETWORK –UDP
F87
DNP Channel 2 Port NONE NONE ; NETWORK-TCP ;
NETWORK –UDP
F87
DNP Address 0 0 to 65519 F1
DNP Client Address 1 0. 0. 0. 0 F150
DNP Client Address 2 0. 0. 0. 0 F150
DNP Client Address 3 0. 0. 0. 0 F150
DNP Client Address 4 0. 0. 0. 0 F150
DNP Client Address 5 0. 0. 0. 0 F150
DNP TCP/UDP Port Number 20000 0 to 65535 F1
DNP Unsol Resp Function Disabled Disabled ; Enabled F126
DNP Unsol Resp Timeout 5 s 0 to 60 s F1
DNP Unsol Resp Max Retries 10 1 to 255 F1
DNP Unsol Resp Dest Addr 1 0 to 65519 F1
DNP Time Sync IIN Period 1440 min 1 to 10080 min F1
DNP Message Fragment Size 240 30 to 2048 F1
