A–24 3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS
2.4 Logical Nodes for generic references. LN Group: G
2.4.1 GGIO (Generic process I/O)
GGIO1: Remote Outputs logical node
GGIO2: Contact I/O logical node
GGIO class
Attribute Name Attr. Type Explanation M/O/C/E Notes
GGIO_0 Generic process I/O
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status information
Ind1 SPS_0 Remote Output 1 O
Ind2 SPS_0 Remote Output 2 O
.. .. .. ..
Ind32 SPS_0 Remote Output 32 O
GGIO class
Attribute Name Attr. Type Explanation M/O/C/E Notes
GGIO_1 Generic process I/O
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Controls
Ind1 SPS_0 Contact input 1 O
Ind2 SPS_0 Contact input 2 O
.. .. .. ..
Ind10 SPS_0 Contact input 10 O
Ind11 SPS_0 Contact Output 1 O
Ind12 SPS_0 Contact Output 2 O
.. .. ..
Ind17 SPS_0 Contact Output 7 O
