ADTS553F
K0553 Revision D
10
[EN] English
ADTS553F
The ADTS553F incorporates all th
e features of the ADTS552F but wi
th an additional Static (Ps2)
port (11), making it a
three channel test set.
Figure 1-3: ADTS553F General Arrangement
11
Static (Ps2) port
23
25
