Chapter 4. Data Sets & Reports
126 USM Go Operator’s Manual
4.9 Fast Report
The Fast Report option performs the same basic function as the Store Report option. The difference is that, if you save the A-Scan screen
image along with the report, the image is saved as a bitmap file. This permits the save operation to be completed significantly faster, but you
should be aware that some SD card printers may not recognize the bitmap file. To use the Fast Report option:
1. Use the joystick ( ) to select the function titled FILENAME. Press the center of the joystick ( ) to activate the function.
2. Move the joystick up or down ( ) to choose the first character in the desired filename. Then, move the joystick left or right
( ) to move the cursor to a different character position in the text string.
3. Repeat step 2 until you have entered the entire file name. Then, press the center of the joystick ( ) to deactivate the function.
4. If you have not already done so, assign the COPY function to one of the Function Toggle buttons (see “Defining Function Toggle
Actions” on page 35). Your report can now be saved by pressing the assigned toggle button, whenever you are in Acquisition Mode and
the cursor is in the menu bar or the full-screen display is active.
