GE Ultrasonic USM Go User Manual

Chapter 5. Data Recorder Files
USM Go Operator’s Manual 131
5.4 Viewing the Data Recorder File
To view the DR file that you have just activated, you must complete the following steps:
1. In the SETUP menu, activate the DR submenu using the joystick ( ).
2. Use the joystick ( ) to select the function titled DR VIEW. Then, press the center of the joystick ( ) to activate the function.
3. Move the joystick left or right ( ) to select the ON option. Then, press the center of the joystick ( ) to deactivate the function.
4. Press and hold the center of the joystick ( ) to switch to the Acquire Menu.
5. When in Acquire Mode, press the center of the joystick ( ) to enter the full-screen display mode.
As shown in Figure 17 on page 132, the DR file is displayed on the right side of the display screen.
