GE Ultrasonic USM Go User Manual

Chapter 5. Data Recorder Files
USM Go Operator’s Manual 133
5.5 Using the Data Recorder File
When the DR file is displayed (see Figure 17 on page 132), the name of the DR file is displayed at the top of the grid, and the currently
selected cell is highlighted. At this point, the following actions may be taken:
IMPORTANT: The two SEND functions described below will not work if the highlighted cell already contains data. You must delete the
existing data first.
• Move the joystick as required ( ) to highlight any desired cell in the grid.
• Use the Function 1 end of the function toggle ( ) to send the current thickness data to the highlighted cell.
• Use the Function 2 end of the function toggle ( ) to send the current thickness data and the A-Scan image to the highlighted cell.
Note: A flag in the upper left corner of a cell indicates that an A-Scan image is attached to the date in that cell.
• Press both ends of the function toggle ( ) simultaneously to delete the contents of the highlighted cell.
Note: In DR mode, the function keys behave as described above, regardless of any previous user-defined actions. However, if the
user-defined HOLD functions have been assigned to these keys, those functions are still available.
