Chapter 1. General Information
2 USM Go Operator’s Manual
1.1 Supplying Power to the Instrument
Figure 1: Rear and Side Views of the USM Go Case
Accessory Mounting Screw
Battery Charger
Connection
1/4-Turn Screw (CW to close, CCW to open)
Slot
Receive Probe
Power ON/OFF
1/4-Turn Screw (CW to close, CCW to open)
Pulse/Transmit Probe
Connection
Connection
