GE Multilin L60 Line Phase Comparison System 5-15
5 SETTINGS 5.2 PRODUCT SETUP
5
5.2.4 COMMUNICATIONS
a) MAIN MENU
PATH: SETTINGS Ö PRODUCT SETUP ÖØ COMMUNICATIONS
b) SERIAL PORTS
PATH: SETTINGS Ö PRODUCT SETUP ÖØ COMMUNICATIONS Ö SERIAL PORTS
The L60 is equipped with up to three independent serial communication ports. The faceplate RS232 port is intended for
local use and is fixed at 19200 baud and no parity. The rear COM1 port type is selected when ordering: either an Ethernet
or RS485 port. The rear COM2 port is RS485. The RS485 ports have settings for baud rate and parity. It is important that
these parameters agree with the settings used on the computer or other equipment that is connected to these ports. Any of
 COMMUNICATIONS

 SERIAL PORTS

See below.
MESSAGE
 NETWORK

See page 5–16.
MESSAGE
 MODBUS PROTOCOL

See page 5–16.
MESSAGE
 DNP PROTOCOL

See page 5–17.
MESSAGE
 DNP / IEC104
 POINT LISTS
See page 5–20.
MESSAGE
 IEC 61850 PROTOCOL

See page 5–21.
MESSAGE
 WEB SERVER
 HTTP PROTOCOL
See page 5–31.
MESSAGE
 TFTP PROTOCOL

See page 5–31.
MESSAGE
 IEC 60870-5-104
 PROTOCOL
See page 5–31.
MESSAGE
 SNTP PROTOCOL

See page 5–32.
MESSAGE
 ETHERNET SWITCH

See page 5–33.
 SERIAL PORTS

RS485 COM1 BAUD
RATE: 19200
Range: 300, 1200, 2400, 4800, 9600, 14400, 19200,
28800, 33600, 38400, 57600, 115200. Only
active if CPU Type E is ordered.
MESSAGE
RS485 COM1 PARITY:
None
Range: None, Odd, Even
Only active if CPU Type E is ordered
MESSAGE
RS485 COM1 RESPONSE
MIN TIME: 0 ms
Range: 0 to 1000 ms in steps of 10
Only active if CPU Type E is ordered
MESSAGE
RS485 COM2 BAUD
RATE: 19200
Range: 300, 1200, 2400, 4800, 9600, 14400, 19200,
28800, 33600, 38400, 57600, 115200
MESSAGE
RS485 COM2 PARITY:
None
Range: None, Odd, Even
MESSAGE
RS485 COM2 RESPONSE
MIN TIME: 0 ms
Range: 0 to 1000 ms in steps of 10
