GE Multilin L60 Line Phase Comparison System C-9
APPENDIX C C.4 GENERIC SUBSTATION EVENT SERVICES: GSSE AND GOOSE
C
–Set CONFIG GSE 1 FUNCTION to “Enabled”.
–Set
CONFIG GSE 1 ID to an appropriate descriptive string (the default value is “GOOSEOut_1”).
–Set CONFIG GSE 1 DST MAC to a multicast address (for example, 01 00 00 12 34 56).
–Set the CONFIG GSE 1 VLAN PRIORITY; the default value of “4” is OK for this example.
–Set the
CONFIG GSE 1 VLAN ID value; the default value is “0”, but some switches may require this value to be “1”.
–Set the CONFIG GSE 1 ETYPE APPID value. This setting represents the Ethertype application ID and must match the
configuration on the receiver (the default value is “0”).
Set the CONFIG GSE 1 CONFREV value. This value changes automatically as described in IEC 61850 part 7-2. For
this example it can be left at its default value.
3. Configure the data by making the following changes in the PRODUCT SETUP ÖØ COMMUNICATION ÖØ IEC 61850 PROTO-
COL Ö GGIO1 STATUS CONFIGURATION settings menu:
–Set
GGIO1 INDICATION 1 to a FlexLogic™ operand used to provide the status of GGIO1.ST.Ind1.stVal (for example,
a contact input, virtual input, a protection element status, etc.).
The L60 must be rebooted (control power removed and re-applied) before these settings take effect.
The following procedure illustrates the reception configuration.
1. Configure the reception dataset by making the following changes in the PRODUCT SETUP ÖØ COMMUNICATION ÖØ IEC
61850 PROTOCOL Ö GSSE/GOOSE CONFIGURATION ÖØ RECEPTION ÖØ CONFIGURABLE GOOSE Ö CONFIGURABLE GOOSE
1 ÖØ CONFIG GSE 1 DATASET ITEMS settings menu:
–Set ITEM 1 to “GGIO3.ST.Ind1.q” to indicate quality flags for GGIO3 status indication 1.
–Set ITEM 2 to “GGIO3.ST.Ind1.stVal” to indicate the status value for GGIO3 status indication 1.
The reception dataset now contains a set of quality flags, a single point status Boolean value, and a floating point ana-
log value. This matches the transmission dataset configuration above.
2. Configure the GOOSE service settings by making the following changes in the
INPUTS/OUTPUTS ÖØ REMOTE DEVICES
ÖØ REMOTE DEVICE 1 settings menu:
–Set
REMOTE DEVICE 1 ID to match the GOOSE ID string for the transmitting device. Enter “GOOSEOut_1”.
–Set REMOTE DEVICE 1 ETYPE APPID to match the Ethertype application ID from the transmitting device. This is “0” in
the example above.
Set the REMOTE DEVICE 1 DATASET value. This value represents the dataset number in use. Since we are using
configurable GOOSE 1 in this example, program this value as “GOOSEIn 1”.
3. Configure the data by making the following changes in the
INPUTS/OUTPUTS ÖØ REMOTE INPUTS ÖØ REMOTE INPUT 1
settings menu:
–Set REMOTE IN 1 DEVICE to “GOOSEOut_1”.
–Set
REMOTE IN 1 ITEM to “Dataset Item 2”. This assigns the value of the GGIO3.ST.Ind1.stVal single point status
item to remote input 1.
Remote input 1 can now be used in FlexLogic™ equations or other settings. The L60 must be rebooted (control power
removed and re-applied) before these settings take effect.
The value of remote input 1 (Boolean on or off) in the receiving device will be determined by the GGIO1.ST.Ind1.stVal value
in the sending device. The above settings will be automatically populated by the EnerVista UR Setup software when a com-
plete SCD file is created by third party substation configurator software.
C.4.5 ETHERNET MAC ADDRESS FOR GSSE/GOOSE
Ethernet capable devices each contain a unique identifying address called a Media Access Control (MAC) address. This
address cannot be changed and is unique for each Ethernet device produced worldwide. The address is six bytes in length
and is usually represented as six hexadecimal values (for example, 00 A0 F4 01 02 03). It is used in all Ethernet frames as
the ‘source’ address of the frame. Each Ethernet frame also contains a destination address. The destination address can
be different for each Ethernet frame depending on the intended destination of the frame.
