C-26 L60 Line Phase Comparison System GE Multilin
C.7 LOGICAL NODES APPENDIX C
C
C.7LOGICAL NODES C.7.1 LOGICAL NODES TABLE
The UR-series of relays supports IEC 61850 logical nodes as indicated in the following table. Note that the actual instantia-
tion of each logical node is determined by the product order code. For example. the logical node “PDIS” (distance protec-
tion) is available only in the D60 Line Distance Relay.
Table C–1: IEC 61850 LOGICAL NODES (Sheet 1 of 3)
NODES UR-FAMILY
L: SYSTEM LOGICAL NODES
LPHD: Physical device information Yes
LLN0: Logical node zero Yes
P: LOGICAL NODES FOR PROTECTION FUNCTIONS
PDIF: Differential Yes
PDIR: Direction comparison ---
PDIS: Distance Yes
PDOP: Directional overpower ---
PDUP: Directional underpower ---
PFRC: Rate of change of frequency ---
PHAR: Harmonic restraint ---
PHIZ: Ground detector ---
PIOC: Instantaneous overcurrent Yes
PMRI Motor restart inhibition ---
PMSS: Motor starting time supervision ---
POPF: Over power factor ---
PPAM: Phase angle measuring ---
PSCH: Protection scheme ---
PSDE: Sensitive directional earth fault ---
PTEF: Transient earth fault ---
PTOC: Time overcurrent Yes
PTOF: Overfrequency ---
PTOV: Overvoltage Yes
PTRC: Protection trip conditioning Yes
PTTR: Thermal overload Yes
PTUC: Undercurrent ---
PTUV: Undervoltage Yes
PUPF: Underpower factor ---
PTUF: Underfrequency ---
PVOC: Voltage controlled time overcurrent ---
PVPH: Volts per Hz ---
PZSU: Zero speed or underspeed ---
R: LOGICAL NODES FOR PROTECTION RELATED FUNCTIONS
RDRE: Disturbance recorder function ---
RADR: Disturbance recorder channel analogue ---
RBDR: Disturbance recorder channel binary ---
RDRS: Disturbance record handling ---
RBRF: Breaker failure Yes
RDIR: Directional element ---
RFLO: Fault locator Yes
RPSB: Power swing detection/blocking Yes
RREC: Autoreclosing Yes
