GE UR series User Manual

5-224 L60 Line Phase Comparison System GE Multilin
5.6 CONTROL ELEMENTS 5 SETTINGS
5
5.6.9 MONITORING ELEMENTS
a) MAIN MENU
PATH: SETTINGS ÖØ CONTROL ELEMENTS ÖØ MONITORING ELEMENTS
b) BREAKER ARCING CURRENT
PATH: SETTINGS ÖØ CONTROL ELEMENTS ÖØ MONITORING ELEMENTS Ö BREAKER 1(2) ARCING CURRENT
 MONITORING
 ELEMENTS
 BREAKER 1
 ARCING CURRENT
See below.
MESSAGE
 BREAKER 2
 ARCING CURRENT
See below.
MESSAGE
 BREAKER
 FLASHOVER 1
See page 5–227.
MESSAGE
 BREAKER
 FLASHOVER 2
See page 5–227.
MESSAGE
 CT FAILURE
 DETECTOR
See page 5–231.
MESSAGE
 VT FUSE FAILURE 1

See page 5–233.
MESSAGE
 VT FUSE FAILURE 2

See page 5–233.
MESSAGE
 OPEN POLE

See page 5–234.
 BREAKER 1
 ARCING CURRENT
BKR 1 ARC AMP
FUNCTION: Disabled
Range: Disabled, Enabled
MESSAGE
BKR 1 ARC AMP
SOURCE: SRC 1
Range: SRC 1, SRC 2
MESSAGE
BKR 1 ARC AMP INT-A:
Off
Range: FlexLogic™ operand
MESSAGE
BKR 1 ARC AMP INT-B:
Off
Range: FlexLogic™ operand
MESSAGE
BKR 1 ARC AMP INT-C:
Off
Range: FlexLogic™ operand
MESSAGE
BKR 1 ARC AMP
DELAY: 0.000 s
Range: 0.000 to 65.535 s in steps of 0.001
MESSAGE
BKR 1 ARC AMP LIMIT:
1000 kA2-cyc
Range: 0 to 50000 kA
2
-cycle in steps of 1
MESSAGE
BKR 1 ARC AMP BLOCK:
Off
Range: FlexLogic™ operand
MESSAGE
BKR 1 ARC AMP
TARGET: Self-reset
Range: Self-reset, Latched, Disabled
MESSAGE
BKR 1 ARC AMP
EVENTS: Disabled
Range: Disabled, Enabled
