6-6 L60 Line Phase Comparison System GE Multilin
6.2 STATUS 6 ACTUAL VALUES
6
b) STATISTICS
PATH: ACTUAL VALUES Ö STATUS ÖØ REMOTE DEVICES STATISTICS Ö REMOTE DEVICE 1(16)
Statistical data (two types) for up to 16 programmed remote devices is shown here.
The StNum number is obtained from the indicated remote device and is incremented whenever a change of state of at
least one DNA or UserSt bit occurs. The SqNum number is obtained from the indicated remote device and is incremented
whenever a GSSE message is sent. This number will rollover to zero when a count of 4 294 967 295 is incremented.
6.2.10 DIGITAL COUNTERS
PATH: ACTUAL VALUES Ö STATUS ÖØ DIGITAL COUNTERS Ö DIGITAL COUNTERS Counter 1(8)
The present status of the eight digital counters is shown here. The status of each counter, with the user-defined counter
name, includes the accumulated and frozen counts (the count units label will also appear). Also included, is the date and
time stamp for the frozen count. The
COUNTER 1 MICROS value refers to the microsecond portion of the time stamp.
6.2.11 SELECTOR SWITCHES
PATH: ACTUAL VALUES Ö STATUS ÖØ SELECTOR SWITCHES
The display shows both the current position and the full range. The current position only (an integer from 0 through 7) is the
actual value.
6.2.12 FLEX STATES
PATH: ACTUAL VALUES Ö STATUS ÖØ FLEX STATES
REMOTE DEVICE 1
REMOTE DEVICE 1
StNum: 0
MESSAGE
REMOTE DEVICE 1
SqNum: 0
DIGITAL COUNTERS
Counter 1
Counter 1 ACCUM:
0
MESSAGE
Counter 1 FROZEN:
0
MESSAGE
Counter 1 FROZEN:
YYYY/MM/DD HH:MM:SS
MESSAGE
Counter 1 MICROS:
0
SELECTOR SWITCHES
SELECTOR SWITCH 1
POSITION: 0/7
Range: Current Position / 7
MESSAGE
SELECTOR SWITCH 2
POSITION: 0/7
Range: Current Position / 7
FLEX STATES
PARAM 1: Off
Off
Range: Off, On
MESSAGE
PARAM 2: Off
Off
Range: Off, On
↓
MESSAGE
PARAM 256: Off
Off
Range: Off, On
