5-34 L60 Line Phase Comparison System GE Multilin
5.2 PRODUCT SETUP 5 SETTINGS
5
5.2.6 REAL TIME CLOCK
PATH: SETTINGS Ö PRODUCT SETUP ÖØ REAL TIME CLOCK
The date and time can be synchronized a known time base and to other relays using an IRIG-B signal. It has the same
accuracy as an electronic watch, approximately ±1 minute per month. If an IRIG-B signal is connected to the relay, only the
current year needs to be entered. See the
COMMANDS ÖØ SET DATE AND TIME menu to manually set the relay clock.
The REAL TIME CLOCK EVENTS setting allows changes to the date and/or time to be captured in the event record.
The
LOCAL TIME OFFSET FROM UTC setting is used to specify the local time zone offset from Universal Coordinated Time
(Greenwich Mean Time) in hours. This setting has two uses. When the L60 is time synchronized with IRIG-B, or has no per-
manent time synchronization, the offset is used to calculate UTC time for IEC 61850 features. When the L60 is time syn-
chronized with SNTP, the offset is used to determine the local time for the L60 clock, since SNTP provides UTC time.
The daylight savings time (DST) settings can be used to allow the L60 clock can follow the DST rules of the local time zone.
Note that when IRIG-B time synchronization is active, the DST settings are ignored. The DST settings are used when the
L60 is synchronized with SNTP, or when neither SNTP nor IRIG-B is used.
Only timestamps in the event recorder and communications protocols are affected by the daylight savings time set-
tings. The reported real-time clock value does not change.
 REAL TIME
 CLOCK
IRIG-B SIGNAL TYPE:
None
Range: None, DC Shift, Amplitude Modulated
MESSAGE
REAL TIME CLOCK
EVENTS: Disabled
Range: Disabled, Enabled
MESSAGE
LOCAL TIME OFFSET
FROM UTC: 0.0 hrs
Range: –24.0 to 24.0 hrs in steps of 0.5
MESSAGE
DAYLIGHT SAVINGS
TIME: Disabled
Range: Disabled, Enabled
MESSAGE
DST START MONTH:
April
Range: January to December (all months)
MESSAGE
DST START DAY:
Sunday
Range: Sunday to Saturday (all days of the week)
MESSAGE
DST START DAY
INSTANCE: First
Range: First, Second, Third, Fourth, Last
MESSAGE
DST START HOUR:
2:00
Range: 0:00 to 23:00
MESSAGE
DST STOP MONTH:
April
Range: January to December (all months)
MESSAGE
DST STOP DAY:
Sunday
Range: Sunday to Saturday (all days of the week)
MESSAGE
DST STOP DAY
INSTANCE: First
Range: First, Second, Third, Fourth, Last
MESSAGE
DST STOP HOUR:
2:00
Range: 0:00 to 23:00
NOTE
