GE Multilin L60 Line Phase Comparison System 6-17
6 ACTUAL VALUES 6.3 METERING
6
The operating signals for the FlexElements™ are displayed in pu values using the following definitions of the base units.
6.3.6 IEC 61580 GOOSE ANALOG VALUES
PATH: ACTUAL VALUES ÖØ METERING ÖØ IEC 61850 GOOSE ANALOGS
The L60 Line Phase Comparison System is provided with optional IEC 61850 communications capability.
This feature is specified as a software option at the time of ordering. Refer to the Ordering section of chap-
ter 2 for additional details. The IEC 61850 protocol features are not available if CPU type E is ordered.
The IEC 61850 GGIO3 analog input data points are displayed in this menu. The GGIO3 analog data values are received
via IEC 61850 GOOSE messages sent from other devices.
6.3.7 WATTMETRIC GROUND FAULT
PATH: ACTUAL VALUES ÖØ METERING ÖØ WATTMETRIC GROUND FAULT 1(2)
This menu displays the wattmetric zero-sequence directional element operating power values.
Table 6–2: FLEXELEMENT™ BASE UNITS
BREAKER ARCING AMPS
(Brk X Arc Amp A, B, and C)
BASE = 2000 kA
2
× cycle
dcmA BASE = maximum value of the
DCMA INPUT MAX setting for the two transducers configured
under the +IN and –IN inputs.
FREQUENCY f
BASE
= 1 Hz
PHASE ANGLE ϕ
BASE
= 360 degrees (see the UR angle referencing convention)
POWER FACTOR PF
BASE
= 1.00
RTDs BASE = 100°C
SOURCE CURRENT I
BASE
= maximum nominal primary RMS value of the +IN and –IN inputs
SOURCE POWER P
BASE
= maximum value of V
BASE
× I
BASE
for the +IN and –IN inputs
SOURCE VOLTAGE V
BASE
= maximum nominal primary RMS value of the +IN and –IN inputs
SYNCHROCHECK
(Max Delta Volts)
V
BASE
= maximum primary RMS value of all the sources related to the +IN and –IN inputs
 IEC 61850
 GOOSE ANALOGS
ANALOG INPUT 1
0.000
MESSAGE
ANALOG INPUT 2
0.000
↓
MESSAGE
ANALOG INPUT 16
0.000
 WATTMETRIC
 GROUND FAULT 1
WATT GND FLT 1:
0.000 W
