GE UR series User Manual

5-210 L60 Line Phase Comparison System GE Multilin
5.6 CONTROL ELEMENTS 5 SETTINGS
5
5.6.5 TRIP OUTPUT
PATH: SETTINGS ÖØ CONTROL ELEMENTS ÖØ TRIP OUTPUT
 TRIP OUTPUT

TRIP MODE:
Disabled
Range: Disabled, 3 Pole Only, 3 Pole & 1 Pole
MESSAGE
TRIP 3-POLE INPUT-1:
Off
Range: FlexLogic™ operand
MESSAGE
TRIP 3-POLE INPUT-2:
Off
Range: FlexLogic™ operand
↓
MESSAGE
TRIP 3-POLE INPUT-6:
Off
Range: FlexLogic™ operand
MESSAGE
TRIP 1-POLE INPUT-1:
Off
Range: FlexLogic™ operand
MESSAGE
TRIP 1-POLE INPUT-2:
Off
Range: FlexLogic™ operand
↓
MESSAGE
TRIP 1-POLE INPUT-6:
Off
Range: FlexLogic™ operand
MESSAGE
TRIP RECLOSE INPUT-1:
Off
Range: FlexLogic™ operand
MESSAGE
TRIP RECLOSE INPUT-2:
Off
Range: FlexLogic™ operand
↓
MESSAGE
TRIP RECLOSE INPUT-6:
Off
Range: FlexLogic™ operand
MESSAGE
TRIP FORCE 3-POLE:
Off
Range: FlexLogic™ operand
MESSAGE
TRIP PILOT PRIORITY:
0.000 s
Range: 0 to 65.535 s in steps of 0.001
MESSAGE
REVERSE FAULT:
Off
Range: FlexLogic™ operand
MESSAGE
TRIP DELAY ON EVOLV
FAULTS: 0.000 s
Range: 0 to 65.535 s in steps of 0.001
MESSAGE
BKR ΦA OPEN:
Off
Range: FlexLogic™ operand
MESSAGE
BKR ΦB OPEN:
Off
Range: FlexLogic™ operand
MESSAGE
BKR ΦC OPEN:
Off
Range: FlexLogic™ operand
MESSAGE
TRIP EVENTS:
Disabled
Range: Enabled, Disabled
