GE Voluson P8 Service Manual

GE DRAFT VOLUSON™ P8/VOLUSON™P6
DIRECTION 5775469, R
EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL
Chapter 5 - Components and Functions (Theory) 5-25
Section 5-3
FrontEnd Processor
Table 5-4 below outlines the Voluson™ P8/Voluson™P6 Front End components described in the sub-
sections.
Figure 5-6 Front End Processor - Block diagram
Table 5-4 Voluson™ P8/Voluson™P6 - Front End components
Sub-section Description Page Number
5-3-1
T-DPI - Probe Interface board
5-26
5-3-2
DBM64G- Beam former board
5-27
5-3-3
DRFG- Radio Frequency interface and System controller
5-28
