GE DRAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

Chapter 7 - Diagnostics/Troubleshooting 7-69

Section 7-11

Error Messages

NOTICE

!! NOTICE:

If the problem (error message) still exists after performing the described actions, call technical support.

Index Error Message Reason Action(s)

01.

When exceeds

15watt

Protection limit

1. See error

message.

2. Activated

probe deselect.

02.

Restart the

system

1. See error

message.

2. Stop

scanning

03.

Restart the

system

1. See error

message.

2. Restart the

system
