GE DRAFT VOLUSON™ P8/VOLUSON™P6
DIRECTION 5775469, R
EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL
Chapter 2 - Site Preparation 2-5
2-2-4 Probe Environmental Requirements
Operation: Ambient temperature 18° to 30° C
Storage: -10° to 50° C
NOTE: Temperature in degrees C. Conversion to degrees F = °C (9/5) + 32.
2-2-5 Time and Manpower Requirements
Site preparation takes time. Begin Pre-installation checks as soon as possible. If possible, allow six
weeks before delivery, for enough time to make necessary changes.
2-2-6 System Specifications
2-2-6-1 Physical Dimensions of Voluson™ P8/Voluson™P6
The physical dimensions and weight (without Peripherals) of the Voluson™ P8/Voluson™P6 unit are
summarized in Tab l e 2- 5 .
NOTE: Physical dimensions (especially height and depth) depend on control console and monitor positioning.
For more details refer to Chapter 2 - System Specifications, on page 2-5.
2-2-6-2 Acoustic Noise Output
max. 55 dB(A)
2-2-6-3 Electrical Specifications
Please refer to Section 2-2-2-1 "Voluson™ P8 / Voluson™P6 Power Requirements" on page 2-3.
!! NOTICE:
SYSTEMS AND ELECTRONIC PROBES ARE DESIGNED FOR STORAGE TEMPERATURES OF
-10 TO + 50
o
C. WHEN EXPOSED TO LARGE TEMPERATURE VARIATIONS, THE PRODUCT
SHOULD BE KEPT IN ROOM TEMPERATURE FOR 10 HOURS BEFORE USE.
!! CAUTION:
Have two people available to deliver and unpack the Voluson™ P8/Voluson™P6.
Attempts to move the unit considerable distances (or on an incline) by one person alone, could
result in personal injury and/or damage to the system.
Table 2-5 Physical Dimensions and Weight (without Peripherals)
Version Height Width Depth Weight
Low 1385 mm 420 mm 670 mm Approximately 68 kg
(without peripherals)
High 1485 mm 420 mm 670 mm Approximately 69 kg
(without peripherals)
