8 - Technical Specifications
131
Temperature and Pressure Ranges
Spray Liquid System
Technical Residue
Residue in the dilutable volume is mentioned in the table below.
The non-dilutable volume varies depending on the boom width and installed options in the fluid system. Worst case
technical residue for the sprayer with the largest tank, largest fluid system and widest spray boom is stated below. Smaller
booms and fluid systems with less options will have less residue.
Filters
The higher the number of mesh, the finer the filtration.
*depending on selected nozzles
Airborne Noise Emission
Airborne noise emission from operating the sprayer relates to the two defined operator positions (in the tractor cab or
operating the chemical incorporator/filling device/TurboFiller). Reference measurements indicate only in the latter case
(operating the chemical filling device) a contribution from the sprayer of additionally 4 dB(A).
Operating temperature range 2 - 40 °C
Operating pressure for the safety valve 15 bar ±1 bar
Max. pressure on the pressure manifold 20 bar
Max. pressure on the suction manifold 1.5 bar
Filter Name/Position
Mesh Mesh Size Colour To p -m o un te d Self-cleaning In-Line Tank Strainer Nozzle
18 1.00 mm White - - - Yes -
300.58 mmGreenYes----
50 0.30 mm Blue Yes - Yes* - Yes*
80 0.18 mm Red Yes Yes Yes* - Yes*
100 0.15 mm Yellow - - Yes* - Yes*
