Hardi MASTER plus HYS User Manual

43
3 - Description
General Info
Overview
An overview of where tanks and equipment are fitted to the sprayer. Some items are optional - depending on your
purchased sprayer model and variant. In addition, note that another boom type is shown on the sprayer overview pictures.
Front view
1. Quick hitch.
2. Power take-off (PTO).
3. Tank level indicator for main tank.
4. Pressure gauge for spray boom (combined with item22).
μ
ATTENTION! Mount the quick hitch on the tractor first
for easy hook-up of the sprayer.
3
2
4
1
1
1
