Hardi MASTER plus HYS User Manual

5 - Operation
76
Symbols for Valves
The following symbols are shown on labels on the sprayer, where the operator can set a valve to stop or start a function.
The labels must be readable when operating the sprayer. Damaged or unreadable labels must be replaced.
The symbols are explained here.
Symbol Symbol Description Label Colour HARDI Item Number
Suction from the MainTank Black / Blue 97816100
Suction from the RinseTank Black / Blue 97816200
Filling of the MainTank from an external tank Black / Blue 97816300
Suction from the FrontTank Black/Blue 97860300
Spraying / Pressurized nozzles Black / Green 97816600
Cleaning the inside of the MainTank Black / Green 97816700
Agitation in the MainTank Black / Green 97817100
TurboFiller Black / Green 97824500
Filling of the FrontTank Black / Green 97826600
Cleaning of empty chemical containers Black / Yellow 97821600
Agitation in the TurboFiller Black / Yellow 97821500
Suction from the TurboFiller to the MainTank Black / Yellow 97821400
