3 - Description
55
Spray Boom
Boom and Terminology
The sprayer is fitted with a VPZ boom. The boom is trapeze suspended and hydraulically operated.
Booms are available in meters working width.
The booms is provided with spring-loaded breakaway on each side.
The terminology is as follows:
A. Centre section
B. Inner wing
C. 1st outer wing
D. 2nd outer wing
E. Breakaway
