HEIDENHAIN ITNC 530 User Manual

HEIDENHAIN iTNC 530 115
3.2 Creating and writing programs
Inserting blocks at any desired location
 Select the block after which you want to insert a new block and
initiate the dialog
Deliberately saving changes
The TNC normally saves changes automatically if you switch the
operating mode or if you select the file manager or MOD function. If
you deliberately want to save changes to the program, proceed as
follows:
 Select the soft-key row with the saving functions
 Press the SAVE soft key for the TNC to save all changes made since
the last time you saved the program
Function Soft key/key
Set the selected word to zero
Erase an incorrect number
Clear a (non-blinking) error message
Delete the selected word
Delete the selected block
Erase cycles and program sections
Insert the block that you last edited or deleted

HEIDENHAIN ITNC 530 Specifications

General

Control Type	CNC
Look-ahead	Yes
Spindle control	Yes
Touch probe cycles	Yes
Operating voltage	24 V DC
Programming	Conversational and DIN/ISO programming
Interpolation	Linear, Circular, Helical
Data Interface	Ethernet, USB, RS-232
Memory	1 GB
Programming Language	HEIDENHAIN plain language
Operating Modes	Manual, Automatic, MDA
Software Options	Various software options available
