Holden Trailblazer Owner Manual (Australia-Localizing-Australia-12333016) -
2019 - crc - 3/2/18
180 Climate Controls
Climate Controls
Climate Control Systems
Air Conditioning System . . . . . . 180
Electronic Climate Control
System . . . . . . . . . . . . . . . . . . . . . . 182
Rear Air Conditioning
System . . . . . . . . . . . . . . . . . . . . . . 184
Air Vents
Adjustable Air Vents . . . . . . . . . . 185
Fixed Air Vents . . . . . . . . . . . . . . . 186
Maintenance
Air Intake . . . . . . . . . . . . . . . . . . . . . 187
Passenger Compartment Air
Filter . . . . . . . . . . . . . . . . . . . . . . . . 187
Air Conditioning Regular
Operation . . . . . . . . . . . . . . . . . . . 187
Climate Control
Systems
Air Conditioning System
{
Warning
Do not sleep in a vehicle with the
air conditioning or heating system
on. It may cause serious harm or
death due to a drop in oxygen
content and/or body temperature.
Controls for:
.
Air distribution (A).
.
Fan speed (B).
.
Temperature (C).
.
Air recirculation
/ (D).
.
Heated rear window
1 (E).
.
Air conditioning
u (F).
Temperature
Adjust the temperature by turning
the knob (C).
Blue : Cold.
Red : Warm.
Air Distribution
Select air outlet by turning the
knob (A).
Y : To head area via adjustable air
vents.
) : To head area and foot well.
6 : To foot well.
- : To windscreen and foot well.
0 : Demisting and defrosting.
