Holden Trailblazer Owner Manual (Australia-Localizing-Australia-12333016) -
2019 - crc - 3/2/18
244 Vehicle Care
.
Reading lamps.
.
Instrument panel lamps.
Caution
Condensation may temporarily
appear on the inside of exterior
lamp lenses after rain or washing
the vehicle. Condensation occurs
when there is a temperature
difference between the inside and
outside of the lamp allowing a fine
mist on the inside surface of the
lamp lens. This condensation will
disappear when the vehicle is in a
dry environment or the lamp is on.
If water does collect in the lamp
contact a Holden Dealer.
Headlamps
High Beam
1. Remove the protective cover.
2. Unplug the connector
from bulb.
3. Press the spring clip outward
and disengage it.
4. Remove the bulb from the
reflector housing.
5. When fitting a new bulb,
engage the lugs in the
recesses on the reflector.
6. Engage the spring clip.
7. Plug the connector onto bulb.
8. Place the protective cover in
the right position and close it.
