Holden Trailblazer Owner Manual (Australia-Localizing-Australia-12333016) -
2019 - crc - 3/2/18
Vehicle Care 249
3. Replace the bulb.
4. Insert and turn the bulb into the
bulb holder and screw it into
place. Install the reverse lamp
assembly in the body and
tighten the screw. Connect the
electrical connector.
5. Switch on the ignition, operate
and check all lamps.
Number Plate Lamp
1. Insert a screwdriver on the left
side of the bulb housing.
2. Press to the side and release
the spring.
3. Remove the bulb housing by
pulling downwards, taking care
not to pull on the cable.
4. Disconnect the electrical
connector.
5. Rotate the bulb holder
anticlockwise to disengage.
6. Remove the bulb from the
holder and replace the bulb.
7. Insert the bulb holder into the
bulb housing by rotating
clockwise.
8. Connect the electrical
connector.
9. Insert the bulb housing into the
tailgate.
10. Check lamp operation.
