Holden Trailblazer Owner Manual (Australia-Localizing-Australia-12333016) -
2019 - crc - 3/2/18
Climate Controls 185
When activated, cold air will flow to
the rear passenger compartment via
the overhead air vents and the front
air conditioning system will switch to
manual mode.
Operation
1. Turn the air conditioning
system on.
2. Press the REAR A/C button.
3. Rotate the rear fan speed
switch to the desired position:
.
Rotate anticlockwise to
decrease air flow.
.
Rotate clockwise to
increase air flow.
Air Vents
Adjustable Air Vents
At least one air vent must be open
while cooling is on in order to
prevent the evaporator from icing up
due to lack of air movement.
Push the adjuster knob up to open
and down to close the vent or to
adjust the volume of air.
